pidbot

pidbot is software created by JLB Controls for tuning industrial PID controllers. It has become an essential tool, helping us rapidly and accurately tune PIDs for the vast majority of process industry applications. We created pidbot as an Ignition® SCADA module to simplify integration and user experience. Install pidbot, and benefit from a simple, effective tuning procedure, standardized across all of your devices, on a familiar platform.

How it Works

1. RECORD
Capture data from your process using the pidbot's recording function, or import process data from another source in Ignition.

2. MODEL
Fit a process model to the data using pidbot's built-in modelling tool.

3. TUNE
Simulate your process under PID control using different tuning values. Use values automatically suggested by pidbot, or adjust manually. Instantly view the impact of tuning adjustments, and select appropriate tuning values.

JLB CONTROLS

PID LOOP TUNING

How it Works

Intuitive PID tuning dashboard built into your SCADA

Intuitive PID tuning dashboard
built into your SCADA
